Product Description

Overview

Featuring an IP45 ("resistant to jets of water from all angles") rated motor, the 5 inch Airflow QuietAir QT120MST may be installed anywhere in the bathroom. Whilst most 240v extractor fans are suitable for bathroom zone 3 only, the QT120MST can be mounted in zones 1, 2 and 3 without the need for a separate 12v transformer. This reduces both product and installation costs and starts saving money before it has even been turned on!

The QT120MST features a motion sensor with overrun timer.

The QuietAir looks great but it also delivers on extraction rate: At 170m3/hr it is one of the most powerful axial bathroom fans available - and actually beats most centrifugal fans too. It doesn't however, blow its own trumpet - at 36dB(A), the Quiet Air certainly lives up to its name. Powerful and quiet, it is also very energy efficient, using only 13w on full power.

Key Features

  • Awarded QuietMark 2014 for kitchen category by Noise Abatement Society
  • Quiet from only 32 dB(A)
  • Power consumption from only 10 watts
  • Two speed options, 42 l/s and 47 l/s
  • Motion sensor with overrun timer
  • High efficiency impeller delivers up to 33 l/s through long lengths of rigid ducting, including 90 degree bends
  • Use in wet zone 1 when protected by an RCD and installed in accordance with latest IEE wiring regulations
  • Integral flow straightener and back draught flap
  • Low specific fan power for SAP assessments
  • Clip-on cover for ease of cleaning
  • Innovative room refresh option (interval timer) programmable for automatic long term routine ventilation
  • Complies with latest 2010 Building Regulations Approved Document F
  • Airflow 41.6/47.2 l/s
  • Airflow @ 31Pa, 33.3 l/s
  • Axial high efficiency impeller
  • Long-life ball bearings with approx. 40,000 hours life
  • Wall/ceiling mounting
  • Sound pressure 32/36 dB(A) @ 3m
  • Fixed run-on timer 15 minutes
  • Power 10/13 watts
  • Low SFP (Specific fan power) 0.24 w/l/s
  • Voltage - 230/1/50-60Hz
  • Rating IP45
  • Max. ambient temperature 40 degree

Specifications

Functionality
PIR
Size
5" / 125mm
Type
Axial
Operation
Intermittent
Colour
White
Voltage
Mains Voltage
IP Rating
IPX5
Guarantee
3 Years
Brand
Airflow
Product Code
AIR 9041500
